Department Spin and Topology in Quantum Materials
PSI
Swiss Light Source (SLS)
User Access
Open call for proposal with two deadlines per year on 15. March and 15. September. The successful proposals are scheduled during the following semester.
Please note that due to the ongoing major upgrade of the SLS, the next call for proposals is planned for spring 2026. Pilot experiments will take place in the 2nd semester of 2025.
Guidelines for a beamtime application can be found here and in the DUO Digital Users Office.
Contact person for users from quantum technology
For instrument specific inquiries the respective instrument scientists.
Instruments especially suited for quantum technology research
|
SLS2.0 – ADRESS2.0 – Soft-X-ray ARPES |
SLS2.0 – ADRESS2.0 – Soft-X-ray RIXS |
SLS2.0 - microXAS2.0 Hard-X-ray Chemical Imaging |
|
|
XPS, XPD/PED, ARPES, XAS, NEXAFS, STM/STS |
Soft-X-ray ARPES/ element-specific ResPES/ XAS at the beamline ADRESS2.0 |
Soft-X-ray RIXS/ non-resonant XES/ XAS at the beamline ADRESS2.0 |
nano/micro-XRF, nano/micro-XRD, nano/micro-XAS |
|
Multi-technique instrument for the characterisation of local atomic and electronic structure at the surface of micro- and nano-structured quantum materials.
|
Soft-X-ray ARPES gives access to fundamental electronic-structure parameters (Fermi surface, electron dispersions and effective masses, electron-boson interactions) with resolution in k-space. The use of soft X-rays allows exploring a wide range of quantum materials from bulk crystals to buried heterostructures and impurities |
Soft-X-ray RIXS gives access to strong electron correlations and electron-boson interactions, by probing the energy and momentum dependence of magnetic, orbital, charge and lattice excitations, for a wide range of quantum materials from bulk crystals to buried heterostructures and two-dimensional materials |
Instrument for multimodal 4D chemical imaging ('chemistry inspace and time'). Special focus on chemical tomography and time-resolved (operando) chemical imaging. Spatial resolution and sensitivity allows the investigation of a wide range of quantum materials from bulk crystals, two-dimensional systems to buried heterostructures and impurities |
|
•Energy range: 85-2000 eV,
•Polarization: linear
•Tunable spot size: 500/50/5 µm
•6-axis sample manipulator
•Temperature range: 35-400 K
•Angle-deflecting ARPES analyzer
•Electric contacts for operando measurements
•In situ UHV transfer to low-temperature STM (4 K) and surface preparation chamber
•Ar glove box with microscope and transfer case
|
•Energy range: 160 – 1600 eV
•Polarizations: linear and circular
•Photon flux: up to 1014 photons/sec/0.01% bandwith at 1 keV
•Optimal grazing-incidence endstation geometry
•Combined energy resolution: up to 15 meV at 1 keV photon energy
•Angular resolution <0.1o
•sample temperature < 8 K
•Operando ARPES and XAS/resonant photoemission
|
•Photon energy: 160 – 1600 eV
•Polarizations: linear and circular
•Photon flux: up to 1014 photons/sec/0.01% bandwith at 1 keV
•c-VLS RIXS spectrometer (10.5 m long) with variable scattering angle (continuous-rotation chamber)
•Combined energy resolution: up to 15 meV at 1 keV photon energy
•Sample temperature < 8 K
•Operando measurements in electric/magnetic fields
•XAS in TEY (drain current) and TFY (photodiode)
|
•Energy range: ~5 – 40 keV
•linear polarization
•Energy resolution:
0.3E-4 | 1.4E-4 •Energy scanning
•Spatial resolution: 200 nm – mm based on dynamic achromatic focusing (2nd development phase: 50 nm based on diffractive optics)
•9-axis (6 DOF) sample manipulator
•Customized flexible endstation modules
•He cryostat
|
|
Open to users from Oct. 2026 Contact: Matthias Muntwiler |
Endstation presently in operation at DESY's beamline P04; back to SLS2.0 from 2026
Access scheme: open user-proposal calls at door.desy.de before 2026 and psi.ch/en/useroffice after
Predecessor beamline ADRESS Contact: Vladimir N. Strocov |
Access scheme: open call for proposals expected in 2027 Predecessor beamline ADRESS Contact: Thorsten Schmitt |
Open call for proposals expected in 2027 Predecessor beamline microXAS Contact: Daniel Grolimund |
SwissFEL
User Access
Open call for proposal with two deadlines per year on 15. March and 15. September. The successfull proposals are scheduled during the following semester.
Guidelines for a beamtime application can be found here and in the DUO Digital Users Office
Contact person for users from quantum technology
For general questions related to QT at SwissFEL: Simon Gerber
For instrument specific inquiries: the respective instrument scientists via emails listed on respective instrument websites.
Instruments especially suited for quantum technology research
|
SwissFEL – Aramis |
SwissFEL - Aramis |
SwissFEL – Athos |
SwissFEL – Athos |
|
XRD, SAXS, WAXS (XAS) at low-temperature and high magnetic fields
|
Ultrafast- (Gi) XRD, BCDI, FT-IXS, XAS, XES, REXS, RIXS
THz to UV pump |
Tr – RIXS, REXS, XAS
THz to UV pump |
Single-shot soft X-ray imaging
UV to IR pump |
|
The Cristallina-Q experimental stations provides unique high-field and low-temperature capabilities to investigate quantum condensed matter systems |
Ultrafast specificity in laser excitation and tender-to-hard X-ray probes down to low Temperature for studying phenomena in condensed matter
|
The Furka experimental endstation is dedicated to the study of quantum materials using time-resolved soft X-ray spectroscopy |
The Maloja endstation is a flexible endstation for exploring novel opportunities in nonlinear X-ray spectroscopy and single-shot imaging |
|
•photon energy: 2.7 - 12.7 keV
•polarization: linear horizontal
•typical relative bandwidth (cumulated): 0.25% fwhm in pink beam, < 0.013% in monochromatic mode
•repetition rate: single shot 0.1 - 100 Hz, shots on demand, custom pulse sequences
•pulse duration: sub-fs up to 70 fs fwhm
•Ultralow-T vector magnet: 0.1 - 1.5 K, 5.2 T vertical / 0.6 T isotropic
•(Pulsed magnet setup: > 20 T, < 4 K)
|
•photon energy: 2 – 13 keV
•polarization: linear horizontal
•typical relative bandwidth (cumulated): 0.25% fwhm, ≤ 0.013 % in monochromatic mode
•repetition rate: single shot - 100 Hz
•pulse duration: 10-70 fs fwhm
•Pulsed laser excitation from THz (≤ 2 MV/cm) to UV
•Sample temperatures ≥ 5 K
•Pump/probe time resolution ≥ 35 fs fwhm; ≤ 100 fs jitter
|
•photon energy: 0.25 – 1.8 keV
•polarization: full flexibility from left/right circular to linear
•typical relative bandwidth (cumulated): 1% fwhm
•repetition rate: 100 Hz
•pulse duration: 10-70 fs fwhm
•X-ray pump-laser arrival-time jitter: < 150 fs fwhm (for time tool options see instrument sections)
•Sample Temperatures ≥ 25 K
•UHV 4-circle diffractometer
•sVLS RIXS spectrometer (6 m long)
|
•photon energy: 0.25 – 1.8 keV
•polarization: full flexibility from left/right circular to linear
•typical relative bandwidth (cumulated): 1% fwhm
•repetition rate: 100 Hz
•pulse duration: 10-70 fs fwhm
•X-ray pump-laser arrival-time jitter: < 150 fs fwhm (for time tool options see instrument sections)
|
