Department Spin and Topology in Quantum Materials
Elettra
Elettra synchrotron
User Access
Typical deadlines: twice a year in March and September for standard proposals for beamtime in the period ca. 6 months later.
CERIC-ERIC offers access to more than 40 different and complementary state-of-the-art techniques, distributed in 8 countries, with the submission of single- or multi-instrument proposals through a single entry point via the VUO.
Help on writing a good proposal and the proposal template
Contact for users from quantum technology
Instruments especially suited for quantum technology research
Elettra and CERIC calls for proposals
|
STXM, Ptychography, XRF |
Low-Energy ARPES |
SPELEEM (XPEEM and LEEM) |
|
TwinMic Microscope combines in a single instrument two operation modes (Full-field Imaging and Scanning Transmission mode) with easy switch between them. |
High flux, high energy resolution, and horizontal-vertical linear polarization for high resolution ARPES experiment sin the low photon energy regime. |
Wide range of complimentary methods provide structural, chemical and magnetic sensitivity with lateral resolution nearing ten nanometers |
|
·Energy range: 400-2200 eV
·STXM: sub-100 nm spatial resolution
·Ptychography: sub-30 nm spatial resolution
·Simple specimen preparation lab
|
·Energy Range: 4.6 – 40 eV
·Temperature range: 5-400 K
·Enhanced bulk sensitivity
·The availability of photon energies below 15 eV is unique for ARPES beamline
|
·Energy range: 25 - 1000 eV
·Imaging techniques: LEEM, EELS-LEEM, XAS-PEEM, XMCD -PEEM, XMCLD-PEEM;
·Microspot diffraction techniques: μ-LEED, μ-ARUPS, μ-ARPES, μ-EELS, μ-XPD
·Microspot spectroscopy techniques: μ-ARUPS, μ-ARPES, μ-XPD, μ-LEED, μ-EELS
·Lateral resolution: 10 nm in LEEM, 30 nm in XPEEM
|
Standard Elettra calls for proposals
| NanoESCA | APE-LE | Spectromicroscopy | |
|
ARPES, XPS, UPS, NEXAFS |
ARPES, spin-ARPES, shallow core XPS, Fermi surface mapping/ tomography |
microARPES, Scanning Time Angle Resolved - Photoemission Electron Microscopy |
|
|
Instrument explores the interrelations between electronic structure and physical properties like magnetism and magnetic phenomena, e.g. by applying synchrotron radiation techniques such as XMCD, XPEEM, photoelectron momentum mapping. |
Facility for spectroscopic investigation of solid surfaces and nanostructured matter where a number of spectroscopic techniques is coupled with sophisticated off-line preparation/growth and characterization tools. |
The unique microscope designed for studies of the local band structure of the materials |
|
|
·Energy range: 5-1000 eV
·Temperature range: 30-400 K
·XMCD, XPEEM, photoelectron momentum mapping
|
·Energy Range: 10-100 eV
·Temperature range: 15-300 K
·Polarization: horizontal, vertical, circular ±
·Coupled with off-line tools: PLD/MBE, atomically resolved STM, LEED-Auger, magneto-optical Kerr effect
|
·Energy Range: 20-310 eV
·Temperature range: 15-470 K
·Energy and angular resolutions: down to 14 meV and 0.150°
·Smallest achievable spot size: 0.5 µm FWHM
|
|
Free Electron laser Radiation for Multidisciplinary Investigations (FERMI)
User Access
Access scheme: FERMI‘s PRP and NFFA calls (June/Nov.)
Help on writing a good proposal and the proposal template
Contact for users from quantum technology
Instruments especially suited for quantum technology research
|
Coherent Diffraction Imaging (CDI), Resonant Coherent Diffraction Imaging (R-CDI) |
Time- and Angle-Resolved Photoemission (TR-ARPES), Time-Resolved Optical Spectroscopy (TR-OS) |
THz fluence dependent spectroscopy, THz-pump/NIR-probe, THz-pump/THz-probe, THz irradiation |
|
The single-shot CDI speckle pattern formed by the short femtosecond FERMI-FEL pulse is an excellent probe to monitor the evolution of the transient states of the sample. Resonant CDI at the atomic absorption edges in a single-shot mode adds elemental sensitivity, while combination with circular or linear polarization, extends the information to spin and orbital momentum. •(linear and circular) polarization
•plane static magnetic field (up to ±35 mT)
|
For both TR-ARPES and TR-OS different setups are offered with various pump and probe energies, repetition rate, time resolution, spot size, probe polarization. ·TR-OS temperature range: down to 4 K, or up to 470 K
·TR-ARPES endstation:
-6-axis cryo-manipulator
-temperatures down to 35 K
-diverse types of in situ sample preparation
|
Ultrashort (100's fs) pulses in the multi THz range with MV/cm electric fields and Tesla magnetic fields. ·THz fluence dependent spectroscopy: saturable absorption and harmonics generation
·THz-pump/NIR-probe (780 or 1560 nm): coupling of the THz degrees of freedom with higher energy excitations
·THz-pump/THz-probe: dynamical evolution of the THz spectrum
·THz irradiation: THz field-induce irreversible changes in matter
|
