BESSY II
User Access
Typical deadlines: twice a year in March (01/03) and September (01/09) for standard proposals for beamtime in the period ca. 6 months later.
*Special access mode: between one and several weeks per semester are reserved for proposals from quantum technology
After initial registration as a user, a two-page PDF document on the scientific context and preliminary work is required. Separately one submits one-page PDF with experimental plan. The beamlines and end stations can be selected online as well as technical parameters required. Guidelines for a beamtime application
Contact person for users from quantum technology
Instruments of BESSY II especially suited for quantum technology research
|
Special access mode |
Special access mode |
Standard access |
Standard access |
|
XPS, NEXAFS |
PEEM, XPS, XMCD, XMLD, Time-resolved absorption |
X-ray Microscopy, NEXAFS, XMCD, XMLD, Time-resolved absorption |
XMCD, XMLD, RIXS |
|
Flexible instrument offers a multi-technique approach for the investigation of the electronic, chemical and structural properties of materials
|
Element-selective and magnetic-sensitive spatially resolved imaging of magnetic and electric domains at high resolution Suitable for studying sub-100nm scale magnetoelectronic devices
|
Element specific, chemically and magnetically sensitive imaging with resolutions <20 nm |
XAS/XMCD measurements, resonant and off resonant soft X-ray scattering, time-resolved ferromagnetic resonance using XMCD in high magnetic fields and for wide temperature range |
|
•Energy range: 80-1500 eV
•Temperature range: 110 – 300 K (measurement), 300-2300 K (sample preparation)
•X-ray absorption is possible in the following modes: fluorescence yield, total and partial electron yields
•Several preparation chambers, fast-load systems, a number of insertion devises such as a flash-machine, evaporators, a heating stage, gas-inlet systems etc. Ar glove box
|
•Energy range: 100 - 1800 eV
•Temperature range: 45 - 600 K
•Magnetic field: holders for in- and out of plane magnetic fields up to 1000 Oe
•Electric field: up to 200 V out of plane
•Ti:Sapphire laser
•Band structure mode at moderate resolution (5 micrometer, 100 meV)
•Suitable for studying sub-100nm scale magnetoelectronic devices
|
•Energy range: 200 - 1900 eV
•Temperature range: RT or 30 – 450 K using cryostat sample holder
•Magnetic fields up to 250 mT
•Time resolution: 100 ps at Multi Bunch (ordinary mode of BESSY II operation) and 10 ps at Low Alpha (special mode)
•Picosecond laser system
•High-frequency electronics for sample excitation and signal detection (> 30 GHz)
|
•Energy range: 20 - 1600 eV
•Temperature range: 0.325 – 500 K
•Single axis magnetic fields:
-9 T along the beam direction
-2T perpendicular to the beam, in the horizontal plane
-1T along the vertical direction.
•Vectorial magnetic fields:
-2T in the horizontal plane
-1T in all directions
-Microwave excitation capability (XFMR)
-Electrical transport capability
|
