3 PANalytical MRD for epitaxy analysis (LMC)

PANalytical MRD for HR-XRD (epitaxy)

PANalytical X'Pert Pro MRD-HR (materials research diffractometer-high resolution) with X-ray mirror, Bartels (4-fold) monochromator, analyzer and PIXcel 1D detector for high-resolution X-ray diffraction.

» X-ray mirror, 4-fold monochromator and analyzer for HRXRD

  • epitaxy
  • reciprocal space maps
  • reflectometry

» Equipment

  • Eulerian cradle (Omega, Phi, Psi)
  • PIXcel line detector
  • X-ray mirror
  • Bartels (4-fold) monochromator
  • Analyzer
  • Triple Axis

Note:

The instrument is highly specialized and requires more time for adjusting, measuring and analyzing. Before booking it is essential that the project is discussed with the lab responsible.

PANalytical MRD for µXRD and epitaxy analysis

PANalytical MRD for µXRD and epitaxy analysis

Left: Extended setup with X-ray mirror, Bartels (4-fold) monochromator, analyzer and triple axis for high-resolution XRD/XRR. Right: Reciprocal space map of GaPN on Si substrate (image courtesy of H. Stange).

Left: Extended setup with X-ray mirror, Bartels (4-fold) monochromator, analyzer and triple axis for high-resolution XRD/XRR. Right: Reciprocal space map of GaPN on Si substrate (image courtesy of H. Stange).
