SolidFlexRIXS
Solid state X-ray emission and NEXAFS with extended temperature range for open port use
The SolidFlexRIXS endstation is dedicated to resonant inelastic x-ray scattering (RIXS) and near edge x-ray absorption fine structure (NEXAFS) investigations of solids. It features an x-ray sensitive single photon-counting detector. The endstation works in UHV. The sample holder is mounted on a continuous flow cryostat for measurements down to 100 K. A custom-designed sample holder is available for sample annealing up to 1500 K during experiments.
Selected Applications:- XAS, XES, RIXS of solid samples
- temperature-dependent spin-flip scattering from XES data
- RIXS-MCD of ferromagnetic materials
- RIXS of carbon allotropes
Methods
RIXS, Time-resolved absorption, XMCD
Remote access
not possible
| Station data | |
|---|---|
| Temperature range | 100 - 1500 K |
| Pressure range | 10-8 mbar |
| Detector | MCP |
| Manipulators | 5 axes motorized |
| Sample holder compatibility | monocrystals, powders, minerals |
| Additional equipment | |
Please contact the Instrument Scientist before applying for experiment time.
