PM3 scattering
Resonant Soft X-ray scattering, NEXAFS, Reflectometry at PM3
PM3 scattering ist ein fest installiertes Experiment am PM3 Monochromator für Transmissions-, Reflexions- und Beugungsmessungen.
Methods
Magnetic Scattering, Reflectivity, EXAFS, NEXAFS, XMCD
Remote access
depends on experiment - please discuss with Instrument Scientist
| Beamline data | |
|---|---|
| Energy range | 20 - 1900 eV |
| Energy resolution | 32000 at 64 eV |
| Flux | 1e9 - 1e10 |
| Polarisation | • horizontal • circular |
| Focus size (hor. x vert.) | 180 µm hor., vert. depends on exit slit |
| Phone | 0049 30 8062 13429 |
| Weitere Details | PM3 |
| Station data | |
| Temperature range | 18 - 400 K |
| Pressure range | 1E-9 - 5E-8 mbar |
| Detector | Si |
| Manipulators | x - y - z, th |
| Sample holder compatibility | Omicron sample holder |
| Additional equipment | rotatable electro-magnet (max 800 mT) |
